The most important plough for primary tillage in canal irrigated or heavy rain areas where there is too much weeds growth. The objective for ploughing with a Mould Board tis to completely invert and pulverize the soil, up-root all weeds, trash and crop residues and bury them under the soil.
The shape of Mould Board is designed to cut down the soil and invert it to right side completely burying the undesired growth which is subsequently turned into a manure after decomposition.
Advantage:
-
• Vital for the maintenance of soil
-
• Improves the soil’s drainage characteristics
-
• Gives the soil a smooth structure
-
• Breaks clods
-
• No need of applying extra pressure as it adapts itself to find the desired depth
-
• Inverts soil to stop the growth of weeds and is essential where weed resurgence occurs frequently
-
• Creates a favourable environment for plants to encourage their healthy growth
-
• Protects farms from pests
-
• Allows for decomposition by burying crop residues.
Technical Specifications:
| Specifications |
2 Furrows |
3 Furrows |
4 Furrows |
| Tractor compatibility |
40 - 65 HP |
65 - 85 HP |
65 - 85 HP |
| Number of Furrow |
2 |
3 |
4 |
| Maximum Width (cm) |
22 |
25 |
28 |
| Working Width (cm) |
70 |
90 |
110 |
| Weight (kg) |
160 |
210 |
260 |
| Linkage Category |
CAT III Point |
